Portable
ADDOTRON
1. Superior Branding with >90% Peak Efficiency Achieving over 90% peak efficiency means less energy is lost to heat during conversion. For B2B buyers, this technical edge acts as a premium differentiator, allowing you to offer a product that provides significantly more actual runtime for devices like laptops and routers compared to low-efficiency competitors. Providing this High-Efficiency Portable Storage directly increases user satisfaction and avoids complaints about under-performing batteries.
2. Universal Compatibility with Pure Sine Wave Output Featuring a stable 50Hz pure sine wave, the LBP series is compatible with everything from IT equipment to small motor-driven tools. Its strong overload capacity ensures it doesn't "pick loads," avoiding the risk of damaging expensive client electronics like high-end workstations or gaming PCs. This versatility allows you to target a wide audience with a single Reliable Emergency Power solution that guarantees safety for all connected devices.
3. High Power Density in a Compact Frame By integrating advanced analog and digital control, Addotron achieves high power density in a small, lightweight package. This compact design lowers your international shipping costs per unit and appeals to urban customers with limited storage space. By offering this Compact Energy Hub, you provide a high-performance solution that fits seamlessly into modern home offices, helping you avoid the logistical complexity of bulkier, less efficient alternatives.
4. Advanced Safety for "Zero-Anxiety" Use Governed by multi-layered hardware and software protection, the LBP series isolates faults instantly to prevent overheating or short-circuits. This extreme reliability helps your business avoid the high costs of warranty claims and protects your brand from the reputational damage associated with safety incidents. Offering a Safe LiFePO4 Energy Storage solution ensures long-term customer loyalty and builds a foundation of trust in your technical expertise.
| Parameters | Technical Specifications | ||
| Product Model | ADDOTRON-LBP200 | ADDOTRON-LBP300 | ADDOTRON-LBP500 |
| Rated Output Power | 200 W | 300 W | 500 W |
| Rated Capacity | 1 kWh | 1 kWh | 1 kWh |
| Output Phase | Single Phase | Single Phase | Single Phase |
| Battery Type | LiFePO4 | LiFePO4 | LiFePO4 |
| Rated Input Voltage | 230 Vac | 230 Vac | 230 Vac |
| Input Voltage Range | 176 ~ 264 Vac | 176 ~ 264 Vac | 176 ~ 264 Vac |
| Rated Input Frequency | 50/60 Hz | 50/60 Hz | 50/60 Hz |
| Power Factor | ≥ 0.97 (Full Load) | ≥ 0.97 (Full Load) | ≥ 0.95 (Full Load) |
| Max Input Current | 1.5 A | 2.0A | 2.5 A |
| Efficiency | 85.0% Max | 85.0% Max | 85.0% Max |
| Battery Rated Voltage | 3.3 Vdc | 3.3 Vdc | 3.3 Vdc |
| Battery Voltage Range | 2.8 ~ 3.65 Vdc | 2.8 ~ 3.65 Vdc | 2.8 ~ 3.65 Vdc |
| Under-voltage Cut-off | 2.8±0.1V | 2.8±0.1V | 2.8±0.1V |
| Over-voltage Cut-off | 3.65±0.1V | 3.65±0.1V | 3.65±0.1V |
| Charging Method | 3-Stage Charging (LiFePO4) | 3-Stage Charging (LiFePO4) | 3-Stage Charging (LiFePO4) |
| Protection (Inverter) | Input Under/Over Voltage, Output Overload, Over-temp, Short Circuit | Input Under/Over Voltage, Output Overload, Over-temp, Short Circuit | Input Under/Over Voltage, Output Overload, Over-temp, Short Circuit |
| Dimensions (HWD) | 290 * 230 * 135 mm | 290 * 230 * 135 mm | 310 * 230 * 150 mm |
| Net Weight | 8.7 kg | 8.7 kg | 12 kg |
| Usage Scenarios | Indoor | Indoor | Indoor |
| Protection Rating | IP21 | IP21 | IP21 |
| Noise Level | < 50 dB | < 50 dB | < 50 dB |
| Operating Humidity | 5% ~ 95% RH | 5% ~ 95% RH | 5% ~ 95% RH |
| Working Temp | -0°C ~ 60°C (Derating above 45°C) | -0°C ~ 60°C (Derating above 45°C) | -0°C ~ 60°C (Derating above 45°C) |
| Storage Temp | -20°C ~ 60°C | -20°C ~ 60°C | -20°C ~ 60°C |
| Max Altitude | 3000 m (Derating above 2000 m) | 3000 m (Derating above 2000 m) | 3000 m (Derating above 2000 m) |
| Cooling Method | Forced Air Cooling (Internal 2x Fans) | Forced Air Cooling (Internal 2x Fans) | Forced Air Cooling (Internal 2x Fans) |
1. Professional Home Office Backup Maintain productivity during unexpected blackouts by powering Wi-Fi routers, laptops, and monitors simultaneously. The LBP series pure sine wave output ensures that sensitive hardware is never rebooted or strained, helping your clients avoid the catastrophic loss of unsaved work and data corruption during critical work shifts.
2. Small-Scale Emergency Power for IT Equipment Ideal for server closets or networking hubs, this Reliable Emergency Power source ensures that critical data links remain active 24/7. Its silent, fan-cooled operation allows it to be placed discreetly indoors, helping businesses avoid the downtime associated with minor grid fluctuations that standard surge protectors cannot handle.
Q: Can this unit run a laser printer?
A: Yes, thanks to its strong overload capacity and pure sine wave, it can handle the initial surge of most office appliances. This adaptability helps your clients avoid device incompatibility issues common with modified sine wave units.
Q: Is it safe for use in high-temperature environments?
A: The unit operates up to 60°C, with power derating above 45°C to protect internal components. This safety feature helps you avoid hardware failures caused by overheating in non-air-conditioned spaces.
Q: How long does it take to recharge via solar?
A: Charging time varies by panel size, but the LBP series efficient energy conversion minimizes waste. By pairing it with Addotron folding panels, you can offer a complete Solar Generator Kit that maximizes energy harvest for your customers.
